PCAN-Ethernet Gateway FD DR – User Manual
4
5 Configuration 27
5.1 Structure of the Website 28
5.1.1 Header 28
5.1.2 Navigation 28
5.1.3 General Symbols 30
5.2 Status 30
5.3 Routing 32
5.3.1 Manage Routes 33
5.3.2 Add / Edit Route 35
5.3.3 Scan for Devices 39
5.4 Filters 40
5.4.1 Manage Filters 40
5.4.2 Add / Edit Filter 41
5.5 Network 44
5.5.1 CAN 45
5.5.2 LAN 51
5.6 Device 53
5.6.1 Device Configuration 54
5.6.2 User Management 57
5.6.3 Device Monitoring 58
5.6.4 Software Update 59
5.7 Help 61
5.8 Support 61
6 Application Examples 62
6.1 Unidirectional Data Transmission 62
6.2 Bidirectional Data Transmission 64
6.3 Filtering Single CAN IDs 67
7 Technical Specifications 70
Appendix A CE Certificate 73
Appendix B Dimension Drawing 74
