PCAN-Ethernet Gateway FD DR – User Manual
60
Perform a software update:
1. Please select the software update package (*.raucb) with
the button on the left.
2. Click the button on the right to upload the file and update
your device. Please note: All routes and CAN interfaces will
be switched to standby for that operation.
3. After a successful software update, the device will reboot.
You will be forwarded to the login page and all routes and
CAN interfaces are reactivated.
Note: If the update process was interrupted, you will have to
restart the device in order to reactivate the routes and CAN
channels. Use the Reboot Device link located near the bottom
of the main navigation. Alternatively you can use the physical
Reset button located on the device itself.
Note: Export your current configuration, if you like to
downgrade to an older software package. The current settings,
routes, and filters may get lost.
Partition Information
The software packages are installed on this PCAN-Gateway
alternately on two partitions. With this, it is possible to go back to
the previous installation in case of problems.
The forms show the version number of the installed software
package and the IP connection settings from the config file for each
partition. The currently active partition is marked red. Each form
provides buttons to download the config file or to activate and
reboot the currently not active partition.
