Cameras
The P354 and P356 have three high- resolution cameras, with PAL or NTSC versions available. All cameras offer
remote focus capabilities and use the latest ultra-bright LEDs for optimum lighting.
Cameras can be fitted direct to the crawler’s body (or to an elevator or lighthead). The cameras can only be fitted in
one alignment. A single 3mm Allen key screw is used to secure the camera to the crawler.
Connecting cameras
Figure 2.4 illustrates the connection of cameras using the C-clamp connection. The procedure is the same for all three
cameras.
Figure 2.4: Connecting a fixed view camera
C-Clamp
C-Clamp modified screw
Figure 2.5: Forward view camera Figure 2.6 Pan & Tilt Camera
Figure 2.7 Pan, Tilt & Zoom Camera
Forward View camera
P350-CAM-FW: this robust and compact camera offers a focal range from 10mm to infinity and a 120 lm light source.
Pan and Tilt camera
P350-CAM-PT The Pan and Tilt camera allows clear vision of pipes. With focal range from 10mm to infinity; featuring
a 210 lm light source.
Pan, Tilt and Zoom camera
P350-CAM-PTZ camera also includes auto-focus, 10x optical zoom with a focal range of 10mm (WIDE) to infinity,
featuring a 420 lm light source.
