6.4.6 Diagnostic
To access diagnostic values, press and hold and for 5 seconds to view the "H" levels.
Diagnosti
c Code
Description Unit Range 762 742
H0 Initial setting value Litre Resin Volume Yes Yes
H1 Day since last regeneration N/A 0 - 255
H2 Current flow rate Depends on turbine used No
H3 Water used today since time of regeneration m
3
0 - 61310.70
H4 Water used since last regeneration m
3
0 - 61310.70
H5 Total water used since reset in 100 s m
3
0 - 9999
H6 Total water used since reset in 1000000 s m
3
4264 x 10
4
H7 Average usage for Sunday m
3
0 - 61310.70
H8 Average usage for Monday m
3
0 - 61310.70
H9 Average usage for Tuesday m
3
0 - 61310.70
H10 Average usage for Wednesday m
3
0 - 61310.70
H11 Average usage for Thursday m
3
0 - 61310.70
H12 Average usage for Friday m
3
0 - 61310.70
H13 Average usage for Saturday m
3
0 - 61310.70
H14 Average service cycle Day 0 - 255
H15 Peak flow rate l/min 0 - 1000
H16 Day and time of peak flow rate Time and day that peak flow
occurred
H17 Months since service Month 0 - 2184 Yes
Hr Number of regenerations since last service N/A 0 - 65536
