Pentax K-1 User Manual

2
Getting Started
35
We recommend the use of the optional AC adapter kit K-AC132
when using the monitor for a long time or when connecting the
camera to a computer or AV device.
1 Make sure that the camera
is turned off, and open the
terminal cover.
2 Align the A marks on the
DC terminal of the AC
adapter and DC input
terminal of the camera, and
connect.
3 Connect the AC adapter to the AC plug cord, and
plug the cord into the power outlet.
u Caution
• Make sure that the camera is turned off before connecting or
disconnecting the AC adapter.
• Make sure that the connections are secure between the
terminals. The memory card or data may be corrupted if the
connection to the power supply is lost while the card is being
accessed.
• Be sure to read the manual of the AC adapter kit before using
the AC adapter.
The following memory cards can be used with this camera.
• SD Memory Card
• SDHC Memory Card
• SDXC Memory Card
In this manual, these cards are referred to as memory cards.
1 Make sure that the camera is turned off.
2 Slide the memory card
cover in the direction of 1
and then rotate it to open
as shown by 2.
3 Insert a card all the way
into each memory card slot
with the memory card label
facing toward the side with
the monitor.
Push the memory card in once
and release to remove.
Using the AC Adapter
Inserting a Memory Card
2
1

Pentax K-1 Specifications

General

Sensor	CMOS
ISO Range	100-204800
Autofocus Points	33
Image Processor	PRIME IV
Viewfinder	Optical (pentaprism)
Video Resolution	Full HD 1080p
Weather Sealing	Yes
Battery Life	760 shots
Camera Type	DSLR
Sensor Size	35.9 x 24 mm
Image Sensor Format	Full Frame
Image Stabilization	Sensor-shift
Continuous Shooting	4.4 fps
LCD Screen Size	3.2 inches
LCD Screen Resolution	1, 037, 000 dots
Battery	D-LI90
Dimensions	136.5 x 110 x 85.5 mm
GPS	Yes
Wi-Fi	Yes
Screen	3.2-inch tilting LCD
Weight	1010g
Shutter Speed	1/8000 to 30 sec
Viewfinder Type	Optical (pentaprism)
Storage Media	SD/SDHC/SDXC
