Pentax K-1 User Manual

3
Shooting
48
1 Display the movie to play
back in single image
display of the playback
mode.
Available operations
t Memo
• The sound volume at the start of movie playback can be set
in [Playback Sound Volume] of the B1 menu. (p.27)
• In [Movie Edit] of the playback mode palette, a movie file can
be divided into multiple segments or selected frames can be
deleted. (p.84)
Using a Microphone or
Headphones
You can reduce the possibility of
recording camera operation
sounds by connecting a
commercially available stereo
microphone to the microphone
terminal on the camera.
The following specifications are
recommended for external
microphones.
You can record and play back movies while listening to the
sound by connecting commercially available headphones to
the headphone terminal.
Microphone terminal
Headphone terminal
Plug Stereo mini plug (ø3.5 mm)
Format Stereo electret condenser
Power
Plug-in Power Method (operating voltage of
2.0 V or lower)
Impedance 2.2 kΩ
Playing Back Movies
A Plays back/pauses a movie.
D Forwards a frame (when
paused).
Press and hold D Fast-forwards playback.
C Reverses a frame (when
paused).
Press and hold C Fast-reverses playback.
B
Stops playback.
R
Adjusts the sound volume (21
levels).
H Saves the displayed frame as a
JPEG file (when paused).
G Switches between [Standard
Information Display] and [No
Information Display].
10'30"10'30"
100-0001100-0001

Pentax K-1 Specifications

General

Sensor	CMOS
ISO Range	100-204800
Autofocus Points	33
Image Processor	PRIME IV
Viewfinder	Optical (pentaprism)
Video Resolution	Full HD 1080p
Weather Sealing	Yes
Battery Life	760 shots
Camera Type	DSLR
Sensor Size	35.9 x 24 mm
Image Sensor Format	Full Frame
Image Stabilization	Sensor-shift
Continuous Shooting	4.4 fps
LCD Screen Size	3.2 inches
LCD Screen Resolution	1, 037, 000 dots
Battery	D-LI90
Dimensions	136.5 x 110 x 85.5 mm
GPS	Yes
Wi-Fi	Yes
Screen	3.2-inch tilting LCD
Weight	1010g
Shutter Speed	1/8000 to 30 sec
Viewfinder Type	Optical (pentaprism)
Storage Media	SD/SDHC/SDXC
