OPC / OPD / OPE
Appendix
2015-07
73
Result data
Event Parameter ID Value Description
From
Firmware
Trigger ResWx Window x:
barcode content
(decoded string
8597
ResWxType DataMatrix
Code128
Code39
EAN/UPC/JAN
2/5 Interleaved
Pharmacode
Window x:
barcode type
8597
ResxTime 0 ... 65535 ms Window x:
Decoding time
8597
ResxQual 0 ... 100%/
0 ... 100%
Window x:
Location quality
horizontal/vertical;
100%/100%
means barcode is
exactly in the
center of the
8597
ShowCounter CtrCaptured 0 ... Number of
captured images
8606
CtrLogoMatch 0 ... Number of
succesful logo
comparisons
8606
CtrFailedRead 0 ... Number of failed
decodings
8606
CtrFailedMatch 0 ... Number of
mismatched
decodings
8606
Table 11.2 Result data
