OPC / OPD / OPE
Appendix
11.2.2 Result overview
Accessing the result data
The sensor transmits result data in the following situations:
■ After transferring each image
■ Trigger
■ Counter value request ("ShowCounter")
The result data is contained in the CONFIGURATION Id=“Result” node. The
node contains two different result parameters depending on the situation.
■ Result data (PF.Foundation.Protocol.XML.ElementResult)
■ Shape data (PF.Foundation.Protocol.XML.ElementShapeBase)
The result data is exclusively text data, which is transmitted in barcode mode and
after Teach-in. The shape consists of either geometrical shapes, such as colored
rectangles (ElementShapeRectangle), or a type label (ElementShapeText).
Result data
The result data is transmitted with the SensorResultDataReceived event and
can be retrieved in the event handler using the GetResultList and
GetResultParameter method.
The following event and parameter IDs are permitted:
BadString string 1 Output string
from bad read;
can contain
placeholders for
inspection
information
8349
Table 11.1 Configuration parameters
Config
ID Parameter ID Value
Config
Version
Description
From
Firmware
Versionfrom to
