OPC / OPD / OPE
Appendix
11.2.1 Configuration Overview
The parameters in the table below can be set using the
SetSpecificSingleParameter and GetSpecificSingleParameter
method in the software interface. Each parameter is identified by a configID and a
parameterID.
Configuration Parameters
Config
ID Parameter ID Value
Config
Version
Description
From
Firmware
Versionfrom to
System EnableRS-232 0, 1 1 Enables RS-
232
5415
DataSize 5, 6, 7, 8 1 RS-232 data
size
5415
StopBits 1, 2 1 RS-232 stop
bits
5415
BaudRate BAUD_115200
BAUD_19200
BAUD_38400
BAUD_57600
BAUD_9600
1 RS-232 baud
rate
5415
ParityMode PARITY_EVEN
PARITY_NONE
PARITY_ODD
1 RS-232 check
bit
5415
TriggerString string 1 RS-232 trigger
string
5415
EnableResultPort 0, 1 1 Enables TCP/IP
result
5415
UDP 0, 1 1 Enables UDP
result
5415
PortOut 1 ... 65536 1 TCP port 5415
PortOutUdp 1 ... 65536 1 UDP port 5415
PosLeds 0, 1 1 Switches
position LEDs
on or off
6106
Enable VGA 0, 1 1 OPE only:
Switches VGA
output on or off
8738
PulseLengthGOOD 1 ... 1000 1 Pulse length in
ms for GOOD
output signal
8474
PulseLengthBAD 1 ... 1000 Pulse length in
ms for BAD
output signal
8474
SensorName string 1 Customizable
string
8470
