ImageFormat 752x480
752x240
752x160
752x120
1 Image capture
area that is
captured and
processed
6022
ImageFinePosition -50 ... +50 1 If the image
format has less
than 480 lines:
vertical line
offset relative to
the center of the
8597
ImageTransfer ALL_IMG
ERROR_IMG
GOOD_IMG
1 Selects images
to transfer to the
connected PC
7818
ImageTransferActive 0, 1 1 Enables or
disables
transmission of
VSX image
information after
each cycle
6064
ImageBuffer ALL_IMG
ERROR_IMG
GOOD_IMG
1 Which images
are to be saved
7818
OverwriteBuffer 0, 1 1 Overwrites the
images in the
memory when
the memory is
full
8473
Camera FlashTime 0 ... 255 1 Sets the flash
time in ms
5415
Gain 0 ... 255 1 Sets the image
capture time in
ms. The
AutoExposure
selection field
must be
disabled
5415
Command TriggerStart 1 1 Triggers an
image capture
5930
BlockTrigger 1 1 Blocks triggers 5971
ResetCounter 1 1 Resets the
counter
8578
GetLastImg 1 1 Requests the
current image
5415
GetErrImg 1 1 Requests the
last fault pattern
5415
SetDefaultParams 1 1 Sets the
parameters to
the factory
settings
7900
Config
ID Parameter ID Value
Config
Version
Description
From
Firmware
Versionfrom to
