OPC / OPD / OPE
Appendix
Trigger
Modes
TriggerMode TRIGGER_DIRE
CT_MODE
TRIGGER_ENC
ODER_MODE
1 Sets the trigger
operating mode
5783
DirectMode TRIGGER_DIRE
CT_EDGE
TRIGGER_DIRE
CT_LEVEL
1 Sets the trigger
signal
characteristics
6022
EdgeMode TRIGGER_EDG
E_POS
TRIGGER_EDG
E_LEVEL
1 Sets the trigger
signal polarity
Rising or falling
edge in
DirectMode =
TRIGGER_DIR
ECT_EDGE
High level or low
level in
DirectMode =
TRIGGER_DIR
ECT_LEVEL
6022
ContinueConn ect 0, 1 1 In DirectMode
operating mode
=
TRIGGER_DIR
ECT_LEVEL:
trigger repeated
when VSX
connection
active
7818
LvlTrigCycle 8 ... 1000 1 Cycle time in
DirectMode
operating mode
=
TRIGGER_DIR
ECT_LEVEL
7869
CreateDebugImage 0, 1 1 Creates and
sends a fault
pattern
6064
EncoderResolution 100 ... 3000 1 OPC and OPD
only: number of
increment
widths per
meter
5988
TriggerOffset 0 ... 32767 1 OPC and OPD
only: offset of
the first trigger
in mm
5988
TargetDistance 70 ... 200 1 OPC only:
distance of the
object from the
sensor in mm
5988
SheetLeng th 100 ... 300 1 OPC and OPD
only: length of
the sheet in mm
5988
Config
ID Parameter ID Value
Config
Version
Description
From
Firmware
Versionfrom to
