OPC / OPD / OPE
Appendix
2015-07
69
DistanceTolerance 0 ... 20 1 OPC and OPD
only: tolerance
for slippage
5988
MoveDirection
MOVE_HOR_N
EGATIVE
MOVE_HOR_P
OSITIVE
MOVE_VER_NE
GATIVE
MOVE_VER_PO
SITIVE
1 OPC and OPD
only: direction of
movement of
sensor
5988
ResetCycle 1 1 OPC and OPD
only: resets an
initiated cycle if
TriggerMode
operating mode
=
TRIGGER_ENC
ODER_MODE
5988
Window N
N = 1, 2, 3,
4
WinActive 0, 1 1 Window N
enabled/disable
d
5415
XStart 0 ... 751 1 X coordinate for
window (ROI)
5415
YStart 0 ... 479 1 Y coordinate for
window (ROI)
5415
RoiWidth 1 ... 752 1 Window width
(ROI)
5415
RoiHeight 1 ... 480 1 Window height
(ROI)
5415
XStart_Pattern 0 ... 751 1 X coordinate for
pattern
comparison
window
5415
YStart_Pattern 0 ... 479 1 Y coordinate for
pattern
comparison
window
5415
RoiWidth_Pattern 64, 128, 196,
256
1 Pattern
comparison
window width
(ROI)
5415
RoiHeight_Pattern 64, 128, 196,
256
1 Pattern
comparison
window height
(ROI)
5415
Config
ID Parameter ID Value
Config
Version
Description
From
Firmware
Versionfrom to
