OPC / OPD / OPE
Appendix
InspectionTask INSPECTION_T
YPE_1_DECOD
E_1D2D
INSPECTION_T
YPE_2_MATCH
_1D2D
INSPECTION_T
YPE_3_MATCH
_LOGO
INSPECTION_T
YPE_4_PRESE
NCE_CHECK
1 Sets the
inspection type
5415
CheckDataMatrix 0, 1 1 Enables or
disables Data
Matrix
5415
CheckInterleave d2of
5
0, 1 1 Enables or
disables
Interleaved 2 of
5
5415
CheckCode128 0, 1 1 Enables or
disables
Code12 8
5415
CheckCode39 0, 1 1 Enables or
disables
Code39
5415
CheckCode13 0, 1 1 Enables or
disables
Code13
5415
CheckPharma 0, 1 1 Enables or
disables
Pharmacode
5415
MinCodeLen1D 0 ... 255 1 Inputs the
minimum code
length
7892
CheckSuml25 0, 1 1 Enables or
disables
checksum test
5716
SuppressDuplicates 0, 1 1 Enables or
disables
suppression of
consecutive
codes with
identical content
7892
MatchString string 1 String for
reading
matches
5415
UpdateMatchString 1 1 Transfers Match
String from last
successful
reading
5716
CheckCheckPosition 0, 1 1 Position check
enabled for
barcodes
5422
Config
ID Parameter ID Value
Config
Version
Description
From
Firmware
Versionfrom to
