OPC / OPD / OPE
Appendix
2015-07
71
deltaX 0 ... 752 1 Horizontal
tolerance for
position check
for barcodes
5415
deltaY 0 ... 480 1 Vertical
tolerance for
position check
for barcodes
5415
PresenceEdgeThres
hold
0 ... 255 1 Edge threshold 8102
PresenceEdgeFilter
Width
1 ... 5 1 Edge filter width 8102
PresenceEdgeRatio
Min
0 ... 2000 1 Edge quotient 8102
PresenceEdgesHoriz
ontal
0, 1 1 Enables/disable
s horizontal
edge calculation
8102
PresenceEdgesVerti
cal
0, 1 1 Enables/disable
d vertical edge
calculation
8102
PresenceInvertOut 0, 1 1 Inverted
evaluation logic
8102
PresenceEdgeImage 0, 1 1 Shows edge
image in original
8102
DataMatrixInvers INVERS_autoCh
ange
INVERS_off
INVERS_on
1 Decoding
process for
inverse Data
Matrix codes
7892
DataMatrixMirror MIRROR_autoC
hange
MIRROR_off
MIRROR_on
1 Decoding
process for
mirrored Data
Matrix codes
7892
Orientation 0 ... 7 1 Permitted
orientations of
the Data Matrix
code
8597
Timeout1D2D 0 ... 65534 1 Timeout for 1-
D/2-D decoding
processes
5415
TimeoutMatch1D2D 0 ... 65534 1 Timeout for 1-
D/2-D decoding
processes
(match)
5415
GoodString string 1 Output string
from good read;
can contain
placeholders for
inspection
information
8349
Config
ID Parameter ID Value
Config
Version
Description
From
Firmware
Versionfrom to
