AS-i 3.0 EtherNet/IP+Modbus TCP Gateway
EtherNet/IP interface
Instances 100 (0x64)…135 (0x87) can only be read, while instances 136
(0x88) …171 (0xAB) can be read and written.
n+20 Slave 29 ch3 high byte
n+21 Slave 29 ch3 low byte
n+22 Slave 29 ch4 high byte
n+23 Slave 29 ch4 low byte
16-bit data of slaves 29 … 31
Tab. 10-10.
Information!
The are only instances 100 (0x64) … 105 (0x69) and 109 (0x6D) … 114 (0x72) in case
of a single master.
