AS-i 3.0 EtherNet/IP+Modbus TCP Gateway
EtherNet/IP interface
26.9.2013
47
Assembly Instance Data Item
input output size
(byte)
digital analog command inter-
face
100 (0x64) 136 (0x88) 16
AS-i circuit 1,
single- and A-slaves
101 (0x65) 137 (0x89) 28 short
102 (0x66) 138 (0x8A) 54 long
103 (0x67) 139 (0x8B) 40
AS-i circuit 1,
analog slaves 29 .. 31
104 (0x68) 140 (0x8C) 52 short
105 (0x69) 141 (0x8D) 78 long
106 (0x6A) 142 (0x8E) 64
AS-i circuit 1+2,
analog slaves 29 .. 31
107 (0x6B) 143 (0x8F) 76 short
108 (0x6C) 144 (0x90) 102 long
109 (0x6D) 145 (0x91) 32
AS-i circuit 1,
all slaves
110 (0x6E) 146 (0x92) 44 short
111 (0x6F) 147 (0x93) 70 long
112 (0x70) 148 (0x94) 56
AS-i circuit 1,
analog slaves 29 .. 31
113 (0x71) 149 (0x95) 68 short
114 (0x72) 150 (0x96) 94 long
115 (0x73) 151 (0x97) 80
AS-i circuit 1+2,
analog slaves 29 .. 31
116 (0x74) 152 (0x98) 92 short
117 (0x75) 153 (0x99) 118 long
118 (0x76) 154 (0x9A) 32
AS-i circuit 1+2,
single- and A-slaves
119 (0x77) 155 (0x9B) 44 short
120 (0x78) 156 (0x9C) 70 long
121 (0x79) 157 (0x9D) 56
AS-i circuit 1,
analog slaves 29 .. 31
122 (0x7A) 158 (0x9E) 68 short
123 (0x7B) 159 (0x9F) 94 long
124 (0x7C) 160 (0xA0) 80
AS-i circuit 1+2,
analog slaves 29 .. 31
125 (0x7D) 161 (0xA1) 92 short
126 (0x7E) 162 (0xA2) 118 long
127 (0x7F) 163 (0xA3) 64
AS-i circuit 1+2,
all slaves
128 (0x80) 164 (0xA4) 76 short
129 (0x81) 165 (0xA5) 102 long
130 (0x82) 166 (0xA6) 88
AS-i circuit 1,
analog slaves 29 .. 31
131 (0x83) 167 (0xA7) 100 short
132 (0x84) 168 (0xA8) 126 long
133 (0x85) 169 (0xA9) 112
AS-i circuit 1+2,
analog slaves 29 .. 31
134 (0x86) 170 (0xAA) 124 short
135 (0x87) 171 (0xAB) 150 long
Tab. 10-11.
