Cellular 1 / Cellular 2
SIM Card IMSI
This is the International Mobile Subscriber Identity which uniquely identifies the SIM card.
This is applicable to 3G modems only.
MEID HEX
The Pepwave MAX supports both HSPA and EV-DO.
For Sprint or Verizon Wireless EV-DO users, a unique MEID identifier code (in
hexadecimal format) is used by the carrier to associate the EV-DO device with the user.
MEID DEC
This is the equivalent of the MEID HEX but in decimal format.
ESN
This serves the same purpose as MEID HEX but uses an older format.
IMEI
This is the unique ID for identifying the modem in GSM/HSPA mode.
Network Mode
Users have to specify the Network they are on accordingly.
WAN Connection
Name
This field is for defining a name to represent this WAN connection.
Standby State
This option allows you to choose whether to remain the connection connected or
disconnected when this WAN connection is no longer in the highest priority and has
entered the standby state. When Remain connected is chosen, upon bringing up this
WAN connection to active, it will be immediately available for use.
Idle Disconnect
When Internet traffic is not detected within the user specified timeframe, the modem will
automatically disconnect. Once the traffic is resumed by the LAN host, the connection will
be re-activated,
Operator Settings
This setting applies to 3G / EDGE / GPRS modem only. It does not apply to EVDO /
EVDO Rev. A modem.
This allows you to configure the APN settings of your connection. If Auto is selected, the
mobile operator should be detected automatically. The connected device will be
configured and connection will be made automatically afterwards. If there is any difficulty
in making connection, you may select Custom to enter your carrier’s APN, Login,
Password, and Dial Number settings manually. The correct values can be obtained from
your carrier.
The default and recommended Operator Settings is Auto.
APN / Login /
Password /
SIM PIN
When Auto is selected, the information in these fields will be filled automatically.
Select the option Custom and you may customize these parameters. The parameters
values are determined by and can be obtained from the ISP.
Heath
Checking
Settings
This setting allows you to specify the health check method for the Cellular connection.
The as available options are Disabled and DNS Lookup.
The default method is DNS Lookup. See Section 8.4 for configuration details.
Bandwidth
Allowance
Monitor
This option allows you to enable bandwidth usage monitoring on this WAN connection
for each billing cycle. When this is not enabled, bandwidth usage of each month is still
being tracked but no action will be taken.
See Section 8.5 for configuration details.
