ACK Timeout
A
This field is for setting the wait time to receive an acknowledgement packet before
performing a retransmission. By default, this field is set to 48 µs.
Frame Aggregation
A
This option allows you to enable frame aggregation to increase transmission
throughput.
Web Administration Settings
Enable
Ticking this box enables web admin access for APs located on the WAN.
Web Access
Protocol
Determines whether the web admin portal can be accessed through HTTP or
HTTPS
Management Port
Determines the port at which the management UI can be accessed.
Admin Username
Determines the username to be used for logging into the web admin portal
Admin Password
Determines the password for the web admin portal on external AP.
Wi-Fi WAN settings can be configured at Advanced>Wi-Fi Settings (or Advanced>Wi-Fi
WAN or some models).
Wi-Fi WAN Settings
Channel Width
Available options are 20/40 MHz and 20 MHz. Default is 20/40 MHz, which
allows both widths to be used simultaneously.
Bit Rate
This option allows you to select a specific bit rate for data transfer over the
device’s Wi-Fi network. By default, Auto is selected.
Output Power
This option is for specifying the transmission output power for the Wi-Fi AP.
There are 4 relative power levels available – Max, High, Mid, and Low. The
actual output power will be bound by the regulatory limits of the selected country.
Note that selecting the Boost
option may cause the MAX’s radio output to
exceed local regulatory limits.
