Name
This field is for specifying a name to represent this profile. The name can be any
combination of alphanumeric characters (0-9, A-Z, a-
z), underscores (_), dashes
(-), and/or non-leading/trailing spaces ( ).
Active
When this box is checked, this VPN connection profile will be enabled. Otherwise,
it will be disabled.
Encryption
By default, VPN traffic is encrypted with 256-bit AES. If Off
is selected on both sides
of a VPN connection, no encryption will be applied.
Authentication
Select from By Remote ID Only, Preshared Key, or X.509
the Pepwave MAX will use to authenticate peers. When selecting
Only, be sure to enter a unique peer ID number in the Remote ID field.
Remote ID /
Pre-shared Key
This optional field becomes available when Remote ID / Pre-shared Key
selected as the Pepwave router’s VPN Authentication
above. Pre-shared Key defines the pre-
shared key used for this particular VPN
connection. The VPN connection's session key will be further protected by the pre-
shared key. The connection will be up only if the pre-
match. When the peer is running firmware 5.0+, this setting will be ignored.
Enter Remote IDs either by typing out each Remote ID and Pre-
pasting a CSV. If you wish to paste a CSV, click the
icon next to the “Remote ID
/ Preshared Key” setting.
Remote
These optional fields become available when X.509 is selected as the Pepwav
e
MAX’s VPN authentication method, as explained above. To authenticate VPN
