Pepwave Peplink MAX Series User Manual

2.2.2 LED Indicators
The statuses indicated by the front panel LEDs are as follows:
Status Indicators
Status
OFF System initializing
Red Booting up or busy
Blinking red Boot up error
Green Ready
Wi-Fi AP and Wi-Fi WAN Indicators
Wi-Fi WAN /
Wi-Fi AP
OFF Disabled Intermittent
Blinking slowly Connecting to wireless network(s)
Blinking Connected to wireless network(s) with traffic
ON
Connected to wireless network(s) without traffic
Cellular Indicators
Cellular 1 /
Cellular 2
OFF Disabled or no SIM card inserted
Blinking slowly Connecting to network(s)
Green
Connected to network(s)
LAN and Ethernet WAN Ports
Green LED
ON 1000 Mbps
OFF
10 Mbps / 100 Mbps or port is not connected
Orange LED
ON Port is connected without traffic
Blinking Data is transferring
OFF Port is not connected
Port Type Auto MDI/MDI-X ports
