Rule Name
This setting specifies a name for the firewall rule.
Enable
This setting specifies whether the firewall rule should take effect. If the box is
checked, the firewall rule takes effect. If the traffic matches the specified
protocol/IP/port, actions will be taken by the Pepwave router based on the other
parameters of
the rule. If the box is not checked, the firewall rule does not take
effect. The Pepwave router will disregard the other parameters of the rule.
Click the dropdown menu next to the checkbox to place this firewall rule on a time
schedule.
WAN Connection
(Inbound)
Select the WAN connection that this firewall rule should apply to.
Protocol
This setting specifies the protocol to be matched. Via a drop-
following protocols can be specified:
● Any
● TCP
● UDP
● ICMP
● DSCP
● IP
Alternatively, the Protocol Selection Tool drop-
automatically fill in the protocol and por
t number of common Internet services (e.g.,
HTTP, HTTPS, etc.)
After selecting an item from the Protocol Selection Tool drop-
protocol and port number remains manually modifiable.
Source IP & Port
This specifies the source IP address(es) and port number(s) to be matched for the
firewall rule. A single address, or a network, can be specified as the
Port setting, as indicated by the following screenshot:
In addition, a single port, or a range of ports, can be specified for the
Port settings.
Destination IP &
Port
This specifies the destination IP address(es) and port number(s) to be matched for
the firewall rule. A single address, or a network, can be specified as the
IP & Port setting, as indicated by the following screenshot:
In addition, a single port, or a range of ports, can be specified for the
IP & Port settings.
Action
This setting specifies the action to be t
aken by the router upon encountering traffic
that matches the both of the following:
● Source IP & port
● Destination IP & port
