2.22.2 LED Indicators

Status Indicators

Status

OFF System initializing

Red Booting up or busy

Blinking red Boot up error

Green Ready

Cellular Indicators

Cellular

OFF Disabled or no SIM card inserted

Blinking slowly Connecting to network(s)

Green Connected to network(s)
