Pepwave Peplink MAX Series User Manual

Cellular Indicators
Cellular
OFF Disabled or no SIM card inserted
Blinking Slowly Connecting to network(s)
Green Connected to network(s)
Wi-Fi Indicators
Wi-Fi / Wi-Fi
AP
OFF Disabled intermittent
ON Connected to wireless network(s)
LAN Ports
Green LED
ON 1000 Mbps
OFF 10 Mbps / 100 Mbps or port is not connected
Orange LED
ON Port is connected without traffic
Blinking Data is transferring
OFF No data is being transferred or port is not connected
Port Type Auto MDI/MDI-X ports
WAN Port
Right LED
ON 1000 Mbps
OFF 10 Mbps / 100 Mbps or port is not connected
Left LED
ON Port is connected without traffic
Blinking Data is transferring
OFF No data is being transferred or port is not connected
Port Type Auto MDI/MDI-X ports

Pepwave Peplink MAX Series Specifications

General

Brand	Pepwave
Model	Peplink MAX Series
Category	Network Router
Language	English
