2-92. Machine Assistant
Bobbin thread monitor
When the bobbin thread is nearing its end the red light next to
the bobbin symbol (A) flashes automatically.
This function is only activated when the hook cover is closed.
Presser foot lifter
The presser foot is raised or lowered with the presser
foot lifter (B).
Bring up the bobbin thread
Raise the presser foot. Hold the needle thread and tap the foot
control until the needle goes down and up one time, or turn the
handwheel towards you until the needle has reached its high-
est position and the bobbin thread has formed a loop. Pull the
needle thread to bring up the bobbin thread.
Close the hook/bobbin door and pull the threads under the
presser foot to the back.
Thread cutter
Pull the threads from the back to the front over the thread
cutter.
