2-32. Machine Assistant
Winding the bobbin from the spool pin
Choose a spool cap slightly larger in diameter than the spool. For
example use the large spool cap for larger spools of thread, and
the smallest cap with cone-type spools. Place the sewing thread
on the spool pin. Slide the cap tightly against the spool.
Threading
Place the thread into guide (A) from front to back and pull it coun-
ter-clockwise above the bobbin winder thread guide (B).
Wind the start of the thread around the bobbin several times in a
clockwise direction.
Note: When bobbin winding always place the thread above the
bobbin winder thread guide (B).
Switch on the main switch.
Start bobbin winding by pushing the bobbin winding lever to the
right. As soon as the bobbin is full, the winding action will be stop-
ped automatically. Cut the thread and remove the bobbin from the
winder.
A
B
