1-22
Creative Data Manager
• TheCreativeDataManagerorganisesyourmachine’sstitches.Hereyouhaveaccesstoseveralfunctions,
such as copying, renaming, moving, sorting, deleting, consulting data in the memory or creating directo-
ries.
• Twoeldsareavailableforprocessing.Botheldscanbeusedassourceordestination,whenyoucopyormo-
ve stitches or stitch sequences.
• Toopendirectories,sub-directories,sequencesorsinglestitchesthereisamarkerbarwhichyoucanmoveup
or down with the arrows.
If the marker bar is on top of a directory name, you always enter a further data record by touching this icon.
Touch this icon to skip from a selected data record to the previous one.
Activity arrows
Using these arrows you can browse through the screen. The dark marker bar indicates the marked area.
Machine’s memory
Use this function to access the stitch selection of the machine or to call up the machine’s memory.
Front card drive
Use this function to access the front card drive.
Rear card drive
Use this function to access the rear card drive.
Copying, renaming, moving
A window is opened for copying, renaming and moving stitches/designs, sequences or combinations.
Copying data:
Youcanduplicatedata,suchasstitchesandstitchsequences,fromthemachineoracreativecardandsavethem
in a different memory or save or insert them on a creative card. To do this, mark your destination file, mark the
source file and touch ’Copy’.
Sequence: 1. Mark destination / 2. Mark source / 3. Copy
Renaming data:
To rename data such as stitches, stitch sequences or personal menus, touch ’Rename’. A window for entering a
new name (max. 8 characters) is opened.
Move:
Youcanmovestitchesorstitchsequencesfromthemachineorfromacreativecardtoanothermemoryorontoa
creative card. To do this, mark your source file, mark the destination file and touch ’Move’.
Sequence: 1. Mark destination / 2. Mark source / 3. Move
Delete:
Use this function to delete a data record (directory, stitch or stitch sequence) that you have marked.
Create a directory
Use this function to create an individual directory for your stitches.
A window in which you can enter a name opens.
Memory information
Use this function to consult the data records contained in a directory or stitch that you have marked.
Sort criterion
Use this function to sort your data alphabetically or according to data type.
If you touch the icon when the sort criterion is set to alphabetical, it is switched to data type, and vice-versa.
Stitch selection
1. If you touch this icon when you have marked a sequence, you can sew it straight away.
The corresponding processing menu for the stitch sequence or embroidery combination appears on the screen.
2. If you touch this icon when a stitch is marked, the processing menu for the stitch appears and the machine is
ready to sew.
3. If you touch this icon when a ’Personal Menu’ is marked, the personal menu is displayed and you can select a
stitch and sew it. The stitch appears on the corresponding processing screen.
