4 Product description
4.1 Product identification
To correctly identify the product when communicating with our service center, always have the informa-
tion from the product rating plate available (see chapter "Labels").
4.1.1 Scope of delivery
●
1 electronic drive unit
●
1 mains socket
●
1 operating instructions
The hand-held remote control (HHR) is not included in the order. To order, see chapter “Ac-
cessories”.
4.1.2 Description
Depending on the ordering guide, the electronic drive unit is equipped with an interface that allows con-
trol through Remote, EtherCAT, Profibus, Devicenet and LonWorks control networks.
As a standard feature, the electronic drive unit is equipped with an RS-232/RS-485 serial link interface.
It can also be controlled with the hand-held remote (HHR) available as an accessory (see chapter “Ac-
cessories”).
In this document, only the operations with the Remote, RS-232/RS-485 and HHR interfaces are descri-
bed.
For the other interfaces, refer to the control interface operating instructions installed on the
pump.
Regardless of the product’s configuration, the electronic drive unit enables a connection to the com-
mand network and display of the pump’s operating condition.
The electronic drive unit is in the form of an electronic module and makes it possible:
●
to power the turbomolecular pump
●
to power and control the water solenoid valve and heating (MT version pump)
●
to power the purge solenoid valves (option) and air inlet solenoid valves (option). These are con-
trolled through the electronic control interface if the wiring and configuration is performed.
Product description
15/60
