1 About this manual
IMPORTANT
Read carefully before use.
Keep the manual for future consultation.
1.1 Validity
This operating instructions is a customer document of Pfeiffer Vacuum. The operating instructions de-
scribe the functions of the named product and provide the most important information for the safe use of
the device. The description is written in accordance with the valid directives. The information in this op-
erating instructions refers to the product's current development status. The document shall remain valid
provided that the customer does not make any changes to the product.
1.1.1 Applicable documents
Document Part Number
Declaration of conformity included with these operating instructions
Profibus Operating instructions 004432
EtherCAT Operating instructions 123800
Devicenet Operating instructions 123801
ATH 1603 M - ATH 2303 M Operating instructions 115101
ATH 2300 M-MT Operating instructions 108895
ATP 2300 M Operating instructions 112419
ATP 1603 M Operating instructions 127646
1.1.2 Products concerned
This document applies to products with the following part numbers:
Description Version of
pump
1)
Part Number
OBC with Remote control panel M 123747 - 127802
OBC with Profibus control panel M 123744 - 127836
OBC with Profibus control MT 123745
OBC with EtherCAT control panel M 124400
OBC with EtherCAT control panel MT 124401
OBC with Devicenet oontrol panel M 126371 - 128246
OBC with Devicenet oontrol panel MT 124402 - 126372
OBC with Lonworks control panel M 128323
OBC with fixed electrical connector and Re-
mote control panel
M/MT 123326
1) OBC is used with ATH 1300, ATH 1600, ATH 1603, ATH 2303, ATP 1300, ATP 1603 magnetically
levitated pumps, version M or MT.
1.2 Target group
This user manual is intended for all persons in charge of transport, installation, commissioning/decom-
missioning, use, maintenance or storage of the product.
The work described in this document must only be carried out by persons with suitable technical training
(specialized staff) or persons who have undergone Pfeiffer Vacuum training.
About this manual
7/60
