15 Technical data and dimensions
15.1 Technical data
Characteristics OBC
Operating voltage 200 V (-15%) to 240 V (+10%)
Power frequency 50/60 Hz
Maximum current 7 A
Maximum power consumption 1000 W
Rated power 750 W
Degree of protection IP 54
Type of cooling water
Cooling water flow rate and temperature (see chapter “Water characteristics”)
Weight 8 kg
Dimensions (see chapter “Dimensions”)
15.2 Environmental conditions
Use indoor use
Installation altitude up to 2,000 m
Ambient operating temperature 5 – +45 °C
Storage temperature -5 – +50 °C
Maximum relative humidity 80 % max. with T ≤ 31 °C at 50 % max. with
T ≤ 40 °C
Transient overvoltage protection
1)
category II
Pollution degree 2
1) Transient overvoltages up to overvoltage category II levels. Temporary overvoltages that affect the
mains supply.
15.3 Electrical characteristics
Main circuit breaker short circuit cut-off capacity 10 kA
Main circuit breaker rating 16 A (for 200-240 V -50/60 Hz
voltage)
GFI (or RCD) type B, differential circuit breaker compatible with
TT electrical networks
30 mA
1)
1) for TN and IT networks, use appropriate protection measures
Tbl. 4: Electrical characteristics of the customer’s network
15.4 Cooling water characteristics
The characteristics below concern only the magnetically levitated turbomolecular pump. This pump is
associated with a backing pump. To ensure the effective operation of the application:
1. Comply with the most restrictive characteristics for the installation.
2. Make sure the water coming from the equipment does not freeze.
Technical data and dimensions
55/60
