1 This label warns users that they risk being injured if their hands come into
contact with a hot surface: wear protective gloves before any intervention.
2 This label indicates that certain internal components carry an electric charge
and can cause electric shock if touched: before working on the pump, always
either disconnect it, or lock out/tag out the installation breaker in the appro-
priate manner.
3
Don’t remove the controller
when the pump is running
This label indicates that the main power supply must not be disconnected
when the electronic drive unit is running.
1.3.4 Abbreviations
IN Inlet flange
Exh. Exhaust
HHR Hand Held Remote
MT Pump version equipped with a temperature management system (TMS)
M Pump version without temperature management system (no TMS)
OBC Electronic drive unit mounted to an active magnetic bearing turbopump
AMB Active magnetic bearings
[XXXX] The HHR remote control unit menus and settings are shown in bold between square
brackets.
For example: [DEFINITION] [LANGUAGE] to select the display language.
1.4 Trademark proof
●
DeviceNet
®
is a trademark of Open DeviceNet Vendor Association Inc.
●
Profibus
®
is a trademark of PI (PROFIBUS & PROFINET International).
●
EtherCAT
®
is trademark and patented technology, licensed by Beckhoff Automation GmbH, Ger-
many.
●
is a trademark of Echelon Corporation.
About this manual
9/60
