List of tables
Tbl. 1: Stickers on the product 9
Tbl. 2: Abbreviations used in this document 10
Tbl. 3: Permissible ambient conditions 17
Tbl. 4: Product designation of Pfeiffer Vacuum HiPace turbopumps 21
Tbl. 5: Turbopump features 21
Tbl. 6: Delivered drive power depending on the supplied mains voltage 21
Tbl. 7: Requirements for the dimensioning of customer-specific high vacuum con-
nection
26
Tbl. 8: Behavior of pumping speed when using a splinter shield or protective screen 27
Tbl. 9: Requirements on the cooling water composition 36
Tbl. 10: Requirements on the cooling water connection 36
Tbl. 11: Factory pre-set accessory connections on the electronic drive unit 37
Tbl. 12: Terminal lay-out of the power supply connector 40
Tbl. 13: Preconfigured settings for turbopumps when delivered 41
Tbl. 14: Behavior and meaning of the LEDs on the electronic drive unit 44
Tbl. 15: Factory settings for delayed venting in turbopumps 45
Tbl. 16: Characteristic nominal rotation speeds of the turbopumps 52
Tbl. 17: Troubleshooting turbopumps 57
Tbl. 18: Available spare parts 60
Tbl. 19: Accessories 63
Tbl. 20: Conversion table: Pressure units 64
Tbl. 21: Conversion table: Units for gas throughput 64
Tbl. 22: Technical data for HiPace 1200 Standard 66
Tbl. 23: Technical data for HiPace 1200 U 67
Tbl. 24: Technical data for HiPace 1200 C 68
Tbl. 25: Technical data for HiPace 1200 UC 69
List of tables
5/74
