Mixing Pump PFT G4
Operation
2007-09-05 47
Removing the mortar hose
Fig. 44: Removing the mortar hose
14. Remove the mortar hose (Fig. 44/1) with the mortar pressure
manometer (
Fig. 44/2).
Rinse out the pump
Fig. 45: Blind cover on the water duct
15. Remove the blind cover (Fig. 45/1) from the lower water duct
(
Fig. 45/2).
16. Remove the material accumulation with a rasp.
17. Press the button
("Water flow ON") in the control panel,
to rinse out the deposits.
Release the button "Water flow ON".
18. Reattach the blind cover (
Fig. 45/1) on the lower water duct
(
Fig. 45/2).
Fig. 46: Water removal
19. Connect the rinsing hose on the water removal connection
(
Fig. 46/1) and open the water removal valve (Fig. 46/2).
20. Switch on the machine via the green "Operation ON"
pushbutton. The green button will be illuminated.
