Appendixes Phason
92 2009-06-15
Setting Actuator 1 Actuator 2 Description
Minimum (stage 0)
Set point c
The temperature below which the actuator is
closed
Position d
The percentage the actuator is open when the
temperature is at or above the minimum set point
Stage 1
Set point c
The temperature at which the actuator starts
opening for stage 1
Differential c
The temperature at which the actuator is open to
stage 1 position
Position d
The percentage the actuator is open when the
temperature is at the differential
Stage 2
Set point c
The temperature at which the actuator starts
opening for stage 2
Differential c
The temperature at which the actuator is open to
stage 2 position
Position d
The percentage the actuator is open when the
temperature is at the differential
Stage 3
Set point c
The temperature at which the actuator starts
opening for stage 3
Differential c
The temperature at which the actuator is open to
stage 3 position
Position d
The percentage the actuator is open when the
temperature is at the differential
Stage 4
Set point c
The temperature at which the actuator starts
opening for stage 4
Differential c
The temperature at which the actuator is open to
stage 4 position
Position d
The percentage the actuator is open when the
temperature is at the differential
Stage 5
Set point c
The temperature at which the actuator starts
opening for stage 5
Differential c
The temperature at which the actuator is open to
stage 5 position
Position d
The percentage the actuator is open when the
temperature is at the differential
c Temperature in °F/°C, range: 0.0 to 37.7°C (32.0 to 99.9°F) d Position in %, range: 0 to 100 %
