Phason PEC Plus - Menu Layout

PEC Plus user manual Becoming familiar with the PEC Plus
31040003 7
Menu layout
The table below shows the layout of the PEC Plus menu system.
Growth curve
>>Parameter A<<
Configuration
1 Current day
2 Curve step
3 Step duration
4 Start temperature
5 Group set point
Variable stages
>>Parameter B<<
Select variable stage 1 or 2
1 “Off at” temperature
2 Idle speed
3 Temperature set point
4 Range temperature
Relays
>>Parameter C<<
Select variable stage 1 or 2
1 Temperature set point
2 Idle band
4 ON duration
5 OFF duration
Actuators
>>Parameter D<<
Select actuator 1 or 2
1 Actuator stage
2 Temperature set point
3 Position
4 Differential
Test
Stage test mode (st9e)
Select variable stage or relay
Actuator 2 utility (a(t2)
Actuator 1 utility (a(t1)
Temperature test mode (tenp)
Alarm enable (ALEn)
High temperature (KieN)
Low temperature (LoEn)
Probe damage (pden)
Probe deviation (pdev)
Actuator 1 jam (a c1e)
Actuator 2 jam (ac2e)
Firmware version (Uer)
Firmware update (Updt)
Factory defaults (FA(t)
Relays (rly)
Select relay 1 to 6
Always off (0ff)
Advanced duty cycle (dt[2)
Actuator 1 (act1) – only for relays 1 and 2
Actuator 2 (act2) – only for relays 3 and 4
Duty cycle heat (dtyk)
Duty cycle cool (dty[)
Heat (keat)
Cool ([ool)
Curtain ([vrt)
Always on (0n)
Variable stages (uar)
Select variable stage 1 or 2
Always off (0ff)
Cool ([ool)
Frequency (freq)
Hysteresis (xyst)
Temperature probes (prob)
Select probe 1 to 4
Probe disabled (p#of)
Probe enabled (p#on)
Probe enabled for outdoor temp (p4ot) – only for probe 4
Temperature units (unit)
Clock ([loc)
Restore settings (rest)
Save settings (saue)
PIN number (pin)
