Chapter 3: Configuring your PEC Plus
Chapter 3 explains how to configure your PEC Plus. Configuring your PEC Plus includes telling it
which equipment is connected to each terminal.
Topics in chapter 3 include:
What you need to know before configuring your PEC Plus below
Configuring the main control functions on page 29
Configuring variable stages on page 33
Configuring relays on page 34
Testing the configuration on page 39
What you need to know before configuring your
PEC Plus
Configuring your PEC Plus means telling it what equipment it will be controlling and how it will be
controlling that equipment. For example, your PEC Plus has 6 relay stages. You need to tell the
stages if they will be controlling curtains, heating or cooling elements, or actuators.
Before you begin configuring your PEC Plus, make sure:
It has power
All equipment has been properly connected to the correct terminals.
You know which equipment is connected to which relays and variable stages
This chapter does not explain set points, idle speeds, or other settings. For
information about those settings, read
Chapter 4: Programming the PEC Plus on
page 41.
