Chapter 4: Programming the PEC Plus Phason
58 2009-06-15
6. To change set point 2, press Up or Down and then press Select.
The control returns to the Parameter menu.
7. To view the ON duration, press 4.
The display shows the current setting.
8. To change the ON duration minutes, press Up or Down and then
press Select. Repeat to change the seconds.
The control returns to the Parameter menu.
9. To view the OFF duration, press 5.
The display shows the current setting.
10. To change the OFF duration minutes, press Up or Down and then press Select. Repeat to
change the seconds.
The control returns to the Parameter menu.
11. Press Back once to return to the Relay menu, or twice to return to the main display.
Programming alarm settings
In addition to the power-failure alarm, there are six other alarms. For a complete list and
descriptions, look at the Alarm settings worksheet on page 95.
High temperature
Low temperature
Probe damage
Probe deviation
Actuator 1 jam
Actuator 2 jam
The alarm settings for your PEC Plus determine which alarm conditions are enabled, which are
disabled, and their settings. All these work together to determine how and when the alarm relay
activates (in other words, signals an alarm condition).
The alarm relay activates if an alarm condition (one that is enabled) is present for longer than the
minimum duration of one minute. The one minute minimum duration prevents alarms from
occurring when the temperature rises or drops for just a few seconds.
When an alarm occurs, the LED for ALARM switches on and the alarm message flashes on the
display. For more information, read Acknowledging alarms on page 62.
