Appendix D: Installation worksheet
Use the worksheet on the next page to list all the equipment (fans, heaters, curtains, and so on that
you want your PEC Plus to control. We recommend you make a copy of the worksheet before
filling it in incase you need more than one sheet or you make a mistake.
Use the
Installation worksheet when you fill in the Configuration worksheets (starting
on page 86).
Input power 120/230 VAC, 50/60 Hz
Variable stages c (2: VARI-1, VARI-2)
Fuses (2: F1and F2)
10 A at 120/230 VAC, general-purpose (resistive)
7 FLA at 120/230 VAC, PSC motor
1/2 HP at 120 VAC, 1 HP at 230 VAC, PSC motor
15 A, 250 VAC ABC-type ceramic
Relay stages c (6: STG-1 to STG-6) 10 A at 120/230 VAC, general-purpose (resistive)
1/3 HP at 120 VAC, 1/2 HP at 230 VAC
360 W tungsten at 120 VAC
Alarm relay 0.4 A at 125 VAC; 2 A at 30 VDC, resistive load
0.2 A at 125 VAC; 1 A at 30 VDC, inductive load
c You can connect more than one piece of equipment to a variable stage or relay as long as they are
the same type (for example, two fans) and the total current draw does not exceed the stage’s limit.
The FLA (full load ampere) rating accounts for the increase in motor current draw
when the motor operates at less than full speed. Make sure the motor/equipment
connected to the variable stage does not draw more than 7 FLA.
