PEC Plus user manual Appendix F: Settings worksheets
31040003 95
Alarm settings worksheet
The alarm settings for your PEC Plus determine which alarm conditions are enabled, which are
disabled, and their settings. All these work together to determine how and when the alarm relay
activates (in other words, signals an alarm condition).
The alarm relay activates if an alarm condition (one that is enabled) is present for longer than the
minimum duration of one minute. The one minute minimum duration prevents alarms from
occurring when the temperature rises or drops for just a few seconds.
For more information, read Programming alarm settings on page 58.
Alarm Status Setting Description
High temperaturec
k-al
ON OFF
The highest temperature to which you can
safely allow your facility to rise – cannot be
lower than low temperature alarm.
Low temperaturec
l-al
ON OFF
The lowest temperature to which you can
safely allow your facility to fall – cannot be
higher than high temperature alarm.
Probe damage
pbad
ON OFF
Damaged or disconnected temperature
probe
Probe deviation
pdeu
ON OFF
The difference in measured temperatures
between averaged probes is greater than
18°F (10°C).
Actuator 1
ac1j
ON OFF
Actuator 1 jammed
Actuator 2
ac2j
ON OFF
Actuator 2 jammed
c Temperature in °F/°C, range: 0.0 to 37.7°C (32.0 to 99.9°F)
