Chapter 5: Monitoring and maintaining your PEC Plus Phason
66 2009-06-15
To display the actuator position
1. Press Function until the LED for TEST is lit.
The display shows st9e.
2. Press Up or Down until the display shows a(t1 (for actuator 1) or
a(t2 (for actuator 2) and then press
Select.
The display shows the position of the actuator, according to the
feedback received from the potentiometer.
3. Press
Back once to return to the Test menu or twice to return to
the main display.
Using PIN security
The PEC Plus has a PIN security feature you can use to control who makes changes to your system
and its settings.
When you enable security, users must enter the PIN (personal identification number) before they
can access the control’s functions. After entering a PIN, you will not be asked again until five
minutes have passed since the last key press.
By default, security is not enabled. When security is not enabled, the PIN is 1111. To enable
security, change the PIN to a different number. The PIN can be any four-digit number, consisting
of the numbers 1 to 5.
To change the PIN
1. Press Function until the LED for CONFIGURATION is lit.
2. Press Up or Down until pin is displayed and then press Select.
The display shows the current PIN.
3. Press
Up or Down to change the digits. Press Select to accept the
number and move to the next digit. After the fourth digit, the
control returns to the Configuration menu.
If the PIN has been forgotten and nobody can access the control, you will have to
reset the PIN security.
a(t1
TEST
50
Pin
CONFIGURATION
1234
