Chapter 2: Installing your PEC Plus Phason
10 2009-06-15
One of the most common causes of power surges is lightning. When lightning strikes the ground, it
produces an enormously powerful electromagnetic field. This field affects nearby power lines, which
transmit a surge to any device connected to it, such as lights, computers, or environmental controls
like your PEC Plus. Lightning does not have to actually strike a power line to transmit a surge.
Surge suppression devices offer some protection from power surges. Because it is not possible to
internally protect this product completely from the effects of power surges and other transients,
Phason highly recommend that you install external surge suppression devices. For specific
recommendations, see your electrical contractor. If you do not take these precautions, you
acknowledge your willingness to accept the risk of loss or injury.
Electrical ratings
Input power 120/230 VAC, 50/60 Hz
Variable stages c (2: VARI-1, VARI-2)
Fuses (2: F1and F2)
10 A at 120/230 VAC, general-purpose (resistive)
7 FLA at 120/230 VAC, PSC motor
1/2 HP at 120 VAC, 1 HP at 230 VAC, PSC motor
15 A, 250 VAC ABC-type ceramic
Relay stages c (6: STG-1 to STG-6) 10 A at 120/230 VAC, general-purpose (resistive)
1/3 HP at 120 VAC, 1/2 HP at 230 VAC
360 W tungsten at 120 VAC
Alarm relay 0.4 A at 125 VAC; 2 A at 30 VDC, resistive load
0.2 A at 125 VAC; 1 A at 30 VDC, inductive load
c You can connect more than one piece of equipment to a variable stage or relay as long as they are
the same type (for example, two fans) and the total current draw does not exceed the stage’s limit.
The FLA (full load ampere) rating accounts for the increase in motor current draw
when the motor operates at less than full speed. Make sure the motor/equipment
connected to the variable stage does not draw more than 7 FLA.
