PEC Plus user manual Servicing and maintaining your PEC Plus
31040003 71
Displaying the firmware version
Firmware is similar to operating system software for a computer. Firmware contains instructions
that tell the PEC Plus how it operates. Just like computer operating systems (such as Windows™
XP) have version numbers, the firmware has a version number.
If you need to contact Phason Customer Support about your PEC Plus, you might need to provide
them with the firmware version of your control. For more information about technical support, read
Service and technical support at the front of the manual.
The PEC Plus displays the firmware version as a number in the format #.##.
To display the firmware version
1. Press Function until the LED for CONFIGURATION is lit.
2. Press Up or Down until uer is displayed and then press Select.
The display shows the firmware version.
3. Press Back twice to return to the main display.
Updating the firmware
The optional PEC+ Updater is an innovative and easy-to-use product that allows you to upgrade
your PEC Plus's firmware. Phason constantly improves and adds new features to their products.
With the PEC+ Updater, you can upgrade the firmware in your PEC Plus as these features become
available. The PEC+ Updater takes only seconds to use and can upgrade all the PEC Plus controls
at your site.
There are two methods for updating the PEC Plus firmware: “power on” and “power off”.
Power on – the power on method allows you to update the PEC Plus firmware using the menu
system, without having to switch the incoming power off and then on. If the power on method
fails, use the power off method.
Power off – the power off method allows you to update the PEC Plus firmware by switching the
incoming power off and then on. Use the power off method if the power on method fails.
The PEC+ Updater works with PEC Plus controls that have a serial number starting
with 2006-10-01 or later. The updater will
not work with serial numbers before that
date.
uer
CONFIGURATION
1
00
