Appendixes Phason
86 2009-06-15
Appendix E: Configuration worksheets
Use the
Installation Worksheet on page 84 when completing the configuration
worksheets.
Main control function worksheet
For each item, circle or write in the configuration.
Item Description Configuration
°C °F
Units
The unit of measure for temperature.
Default: °F
P1: on off
P2: on off
P3: on off
P4: on off outdoor
Probes
The configuration for each temperature probe
terminal.
Default: P1-on, P2 to P4-off
_______ degrees
Hysteresis
The number of degrees above the set point that a
heating stage or relay switches off, and the
number of degrees below the set point that a
cooling stage or relay switches off.
Range: 0.3 to 5.0°F (0.2 to 2.8°C)
Default: 1.0 °F
