PEC Plus user manual Testing settings and equipment
31040003 65
over a full range of temperatures. The variable stages and relays remain operating according to the
test temperature until you exit temperature test mode.
When the PEC Plus is in temperature test mode, it does not operate the equipment
according to the measured temperature.
The PEC Plus does not exit test mode automatically. When you are finished testing,
press
Back until the control exits test mode.
To test equipment using temperature test mode
1. Press Function until the LED for TEST is lit.
The display shows st9e.
2. Press
Up or Down until the display shows tenp and then press
Select.
The display shows the last ambient temperature (now the “test
temperature”).
3. Press Up or Down to adjust the test temperature.
The variable stages and relays operate using their programmed settings according to the test
temperature. When a stage or relay switches on, its LED switches on.
4. When done, press Back twice to return to the main display.
The control returns to normal operation.
Using the actuator 1 and 2 test utilities
The actuator 1 and actuator 2 test utilities display the position of the actuator, according to the
feedback received from the feedback potentiometer. Actuator 1 shows the value for the
potentiometer connected to terminals ACT-1 on the control board and actuator 2 shows the value
for the potentiometer connected to ACT-2.
If the actuator has not been calibrated, the display shows u(al.
Tenp
TEST
