Chapter 4: Programming the PEC Plus Phason
48 2009-06-15
Use the
Variable stage settings worksheet on page 90 when programming variable
stages.
To program variable stages
1. Press Function until the LED for VARIABLE STAGES is lit.
The display shows uar1 (variable stage 1).
2. Press Up or Down to toggle between programming variable stage 1
and variable stage 2 and then press Select.
The display shows parb (parameter B). The LEDs for STAGES
show which stage you are programming.
3. To view the “off at” temperature, press 1.
The display shows the current setting.
4. To change the setting, press Up or Down and then press Select.
The control returns to the Parameter menu.
5. To view the idle speed, press 2.
The display shows the current setting.
6. To change the idle speed, press Up or Down and then press Select.
The control returns to the Parameter menu.
7. To view the temperature set point, press 3.
The display shows the current setting.
8. To change the set point, press Up or Down and then press Select.
The control returns to the Parameter menu.
9. To view the range (on full at) temperature, press
4.
The display shows the current setting.
10. To change the range temperature, press Up or Down and then press
Select.
The control returns to the Parameter menu.
11. Press Back once to return to the Variable stage menu, or twice to return to the main display.
To view the settings for a step, select the step (read steps
2 and 3 above) and then
press the Parameter buttons for the settings you want to view. Repeat this for each
step you want to view.
o750
VARIABLE STAGES
T800
; 20
r860
VAR1
uar1
