Chapter 4: Programming the PEC Plus Phason
60 2009-06-15
To program high and low temperature alarm settings
1. Press Function until the LED for RELAYS is lit.
The display shows rly1 (Relay 1).
2. Press Down until the display shows LoaL (low temperature alarm)
and then press Select.
The current setting flashes.
3. Press Up or Down to change the setting and then press Select.
The control returns to the Alarm/Relay menu.
4. Press
Down until the display shows x;aL (high temperature alarm)
and then press
Select.
The current setting flashes.
5. Press Up or Down to change the setting and then press Select.
The control returns to the Alarm/Relay menu.
6. Press Back to return to the main display.
RELAYS
Loal
LARM
600
x;al
