The Conditional Access Interface supports direct control and
communication to the PC-Card attached to a PCMCIA
interface. The interface supports the DVB CI-CA and
CableCard specification.
9.7 Back-end
Refer to figures “Architecture of TV520 platform” earlier in this
chapter for details. Refer also to block diagrams B04, B05 and
B06.
Table 9-1 Back-End key component overview
9.7.1 HD sets @ 50 / 100 Hz
In HD sets (50 / 100 Hz), the output signal coming from the
PNX8535 is fed to the PNX5050 and then to the PACIFIC 3; the
PACIFIC 3 also drives the AmbiLight units. The PACIFIC 3 also
generates the pulse-width modulated signal needed for the
“Dimming Backlight” feature, which ensures additional motion
sharpness. As some displays require an analogue signal to
switch the LCD, a multiplexer is added to transform the puls-
width modulated signal. An additional signal, coming from the
PNX8535, makes the selection between analogue and pulse-
width modulation, depending on which display is used.
Scanning Backlight displays require an analogue signal, and all
other displays a pulse-width modulated.
Refer to figure “Block diagram display control HD-sets 50 / 100
Hz”.
Figure 9-13 Block diagram display control HD-sets 50 / 100 Hz
