Philips Q528.1E - 4 Mechanical Instructions; Cable Dressing

Mechanical Instructions
EN 8 Q528.1E LA4.
4. Mechanical Instructions
Index of this chapter:
4.1 Cable Dressing
4.2 Service Positions
4.3 Assy/Panel Removal
4.4 Set Re-assembly
Notes:
• Figures below can deviate slightly from the actual situation,
due to the different set executions.
• Follow the disassemble instructions in described order.
They apply to the 47PFL9532D/10 (47” with AmbiLight),
unless stated otherwise.
4.1 Cable Dressing
Figure 4-1 Cable dressing 32” sets
H_16800_136.eps
100507
