2-4
Symbols
Oxygen
(Yellow) Warning
Ethernet connection
Accept button on the top-right front of the ventilator
Adjustment direction on the navigation ring (legacy versions only)
Canadian Standards Association approval
Do not disassemble. Refer to authorized service personnel.
Product must be disposed of in accordance with the WEEE directive.
Noninvasive ventilation (patient with mask)
Invasive ventilation (intubated patient)
The V60/V60 Plus Ventilator is MR Unsafe and presents a projectile haz-
ard. Keep the ventilator outside MRI scan room (Zone IV).
Table 2-1: Symbols used on ventilator labels, battery, and packaging
Symbol Description
