Symbols
2-5
Do not block the cooling fan Inlet (at the rear of the ventilator).
Used in conjunction with the blue “consult accompanying documents”
symbol to indicate “Do not block the cooling fan Inlet.”
No pushing. Do not push on the ventilator screen. Tipping hazard.
Total mass (weight). See page 11-6 for details on physical characteristics
of the ventilator, stand, and accessories.
Hospital-grade
Packaging unit. Symbol accompanied by a number (indicating the
number of pieces in the package)
Recycle
Recycle (Taiwan)
RoHS (China). Administrative Measure on the Control of Pollution Caused
by Electronic Information Products. Contains RoHS substances with 50
years environmentally friendly use period (EFUP).
uR UL recognition symbol
Direct current (DC). Symbol is on backup battery.
Battery check.
Table 2-1: Symbols used on ventilator labels, battery, and packaging
Symbol Description
