FL MGUARD RS2000 TX/TX-B
105656_en_05 PHOENIX CONTACT 117
5.7 Technical data
Hardware properties FL MGUARD RS2000 TX/TX-B
Platform Freescale network processor with 330 MHz clocking
Network interfaces 1 LAN port | 1 WAN port
Ethernet IEEE 802.3 10/100 Base TX
RJ45 | full duplex | auto MDIX
Other interfaces Serial RS-232
D-SUB 9 plug
2 digital inputs and 2 digital outputs (not all used)
Memory 128 MB RAM | 128 MB Flash
SD card
Replaceable configuration memory
High availability options None
Power supply Voltage range 11 ... 36 V DC
Power consumption 2.13 W, typical
Humidity range 5% ... 95% (operation, storage), non-condensing
Degree of protection IP20
Temperature range -20°C ... +60°C (operation)
-20°C ... +60°C (storage)
Dimensions (H x W x D) 130 x 45 x 114 mm (up to DIN rail support)
Weight 725 g
Weight (incl. packaging) 900 g
Firmware and power values FL MGUARD RS2000 TX/TX-B
Firmware compatibility mGuard v8.x or later: Phoenix Contact recommends the use of the latest firm-
ware version and patch releases in each case.
For the scope of functions, please refer to the relevant firmware data sheet.
Data throughput Bidirectional throughput: 120 Mbps, maximum
Management support Web GUI (HTTPS) | command line interface (SSH) | SNMP v1/2/3 | central
device management software
Diagnostics LEDs (Power 1 + 2, State, Error, Signal, Fault, Modem, Info) signal contacts |
service contacts | log file | remote syslog
Other FL MGUARD RS2000 TX/TX-B
Conformance CE | UL 508
Special features Realtime clock | temperature sensor
